Name: | Curved glass |
---|---|
Radius: | 200mm-2800mm |
Max Arch Height: | 1200mm |
Max size: | 28008000mm |
Thickness of glass: | 3mm-25mm |
Product Description
Curved Glass
Curved glass is to use common flat glass classics mechanical gush arenaceous, manual grind (be like emery grind) or chemical method is handled, then also a kind of pre-stressed glass, the usual method of tempering is changing the curved radians of the front and back on the basis of the same direction of the glass according to the requirement.
Hot curved glass is made of float glass which is firstly heated to soften point on metal mould and then curved to shape by weight of glass itself and outside force, and finally cooled down.
Specification:
Thickness of glass: 3mm-25mm
Max size:2800*8000mm
Min size: 50*50mm
Radius: 200mm-2800mm
Max Arch Height:1200mm
Futures:
Good accuracy in arc, less light aberration.
Application:
curtain wall with curved structure, skylight, sightseeing elevator, indoor glass partition with curve structure,
glass enclose etc.
